Power HD T60-BHV Brushless Servo
The Power HD T60 High Voltage Servo feature all-aluminium housings, with high-power brushless motor as the core power, offering amazing torque output. American imported ST32-bit MCU control chip ensure superior servo performance. The T60 is ideal for 1/8th nitro off-road.
T60-BHVTorque(6.0V): 45.0 kg-cm / (624.9 oz/in)
Torque(7.4V): 50.0 kg-cm / (694.4 oz/in)
Torque(8.4V): 60.0 kg-cm / (833.2 oz/in)
Speed: 0.098 sec (6.0V) │ 0.089 sec (7.4V)
Speed: 0.080 sec (8.4V)
| Operating Voltage | 6.0v | 7.4v | 8.4v |
| Torque | 45.0 kg-cm / (624.9 oz/in) | 50.0 kg-cm / (694.4 oz/in) | 60.0 kg-cm / (833.2 oz/in) |
| Speed | 0.098 sec | 0.089 sec | 0.080 sec |
| Bearing Type | Ball Bearing x 2 | ||
| Motor Type | Brushless Motor | ||
| Gear Type | Steel | ||
| Working frequence | 1520μs / 333hz | ||
| Operating temperature | -20℃~60℃ | ||
| Weight | 83 g (2.93 oz) | ||
| Size | 40.7 x 20.5 x 38.7 mm ( 1.60 x 0.81 x 1.52 in) | ||
